Open source · Go · IPv4 · CLI

A million IPs.
A handful of ranges.

flokbn is a Go CLI that clusters the IPs in your access logs into CIDR ranges. A binary trie does the heavy lifting - a 2-million-line log takes about a second on an ordinary workstation. Use it for botnet detection, abuse analysis, or building ban lists.

Quick start CLI reference

static for historical logs · live for real-time banning · JSON / plain / TUI output

~4M requests/sec measured parse rate, full parse on the reference dataset

~50ms trie build for ~1.2M unique IPs on the reference dataset

<1ms cluster detection across multiple cluster arg sets

~50B memory per unique IP in the trie - usage scales linearly

Measured on a 2.3M-request real-world dataset on a single Linux workstation - your numbers will vary with hardware and log shape. Full benchmarks →

00 / SEE IT RUN

One command from raw log to clustered ranges

Point flokbn static at an access log and give it one or more cluster arg sets - minSize,minDepth,maxDepth,threshold. Each set is a detection tier: tight ones catch single hot hosts, loose ones catch whole subnets misbehaving together.

Multiple detection tiers in a single pass
Whitelists protect monitoring and partner IPs
Plain or JSON output you can script into iptables, nftables, or a WAF

Static analysis guide →

flokbn static - illustrative output, RFC 5737 ranges

$ flokbn static --logfile /var/log/nginx/access.log \
    --clusterArgSets 1000,24,32,0.1 \
    --clusterArgSets 10000,16,24,0.2 --plain

ANALYSIS OVERVIEW
────────────────────────────────────────────
Total Requests:  2,345,057
Parse Rate:      4,388,769 requests/sec
Duration:        570 ms

CLUSTERING RESULTS (2 sets)
────────────────────────────────────────────
Set 1: min_size=1000, depth=24-32, threshold=0.10
  192.0.2.86/32        1,574 requests  (  0.07%)
  198.51.100.192/26    3,083 requests  (  0.13%)

Set 2: min_size=10000, depth=16-24, threshold=0.20
  203.0.113.0/24      52,868 requests  (  2.25%)
  198.51.100.0/24     28,812 requests  (  1.23%)

01 / HOW IT WORKS

Five stages, one pass

1
Parse
Configurable format strings read Apache, Nginx, or custom logs. An IP-only fast path skips every field the analysis doesn’t need.
Log formats
2
Filter
Time windows, whitelist/blacklist files, and regex filters on User-Agent and endpoint - with a literal prefilter so the regex engine rarely runs.
Filtering
3
Build trie
Every surviving IP is inserted into a binary trie - on the reference dataset, clustering then runs in microseconds per arg set.
Internals
4
Detect clusters
Configurable depth ranges and thresholds walk the trie and emit the CIDR ranges where traffic concentrates.
Clustering
5
Jail
Detected ranges land in a persistent jail - the state your firewall automation reads to ban and unban.
Jail system

02 / TWO MODES

Analyze logs after the fact, or watch them live

flokbn static

Static analysis

Analyze historical log files. Slice by time window, query specific CIDR ranges, and - when the use case calls for it - generate a ban-candidate list from what actually happened.

Multi-tier detection with several cluster arg sets per run
Time-window filtering for forensic slices
JSON, compact JSON, plain text, or interactive TUI

Static analysis guide →

flokbn live

Live protection

Continuous monitoring over the Lumberjack protocol (Filebeat-compatible). Sliding windows watch traffic in real time; detected ranges are banned automatically.

Bounded memory via slidingWindowMaxSize
Persistent jail state with escalating ban stages
HTTP /stats, /bans and Prometheus /metrics endpoints
Docker demo stack - closed-loop firewall with a Grafana dashboard

Live protection guide →

03 / FEATURES

What’s in the box

/01

Automatic clustering

IPs group into CIDR ranges without manual configuration - you tune size, depth, and threshold, the trie does the rest.

/02

Multi-trie detection

Run several detection configurations simultaneously in one pass - one log read, many perspectives.

/03

Flexible filtering

Whitelist and blacklist files, regex on User-Agent and endpoint, and time-based windows - combined freely.

/04

Block list generation

Inspired by fail2ban: the output is a list of CIDR ranges with request counts - a ready-made candidate list for bans or rate limits.

/05

Four output formats

JSON for pipelines, compact JSON for storage, plain text for humans, and an interactive TUI for exploration.

/06

Speed as a feature

Zero-copy chunked I/O, an IP-only parse path, regex literal prefiltering, memory pools - the performance work is documented and benchmarked.

04 / THE DOCS

Scope, stated plainly

IPv4 only. IPv6 is not implemented yet.
Live mode ingests via Lumberjack. HTTP/JSON API support is planned.
One %h field per log format. Multiple IP fields are not supported.
No duplicate field specifiers in a log format string.

Full limitations →

Cluster your first log
in five minutes.

Quick start View on GitHub
